4. Hardware Installation
Because there are large differences between PC's, we can give you only a general installation
guide for the EX-1170HMVS. Please refer your computer's reference manual whenever in doubt.
1. Install the EX-1170HMVS to the wall or to a DIN-Rail if required.
2. Connect the USB 2.0 cable with the USB 2.0 Upstream B-Port at the EX-1170HMVS.
3. Connect the optional power supply to the DC-Connector or to the Terminal Block at the Hub.
4. Now connect the other end from the USB 2.0 cable (A-Plug) to the USB A-Port at your PC.
© Copyright 2023 by EXSYS Vertriebs GmbH. All Rights Reserved
DIN-Rail Clip
Holes for
Wall Installation
12
EX-1170HMVS
Installation to
DIN-Rail
