ASSEMBLY
1
Hardware Qty
A Bolt 8
B Flat Washer 8
A
B
2
Hardware Qty
C Bolt 2
D Screw 2
D
C
ENGLISH
3
Hardware Qty
E Bolt 4
F Tooth Washer 4
G Screw (pre-installed) 6
H Screw 2
I Bolt 2
G I
4
Hardware Qty
J Bolt 4
J
9
H
E
F
G
