Humidity Module (Optional); Colour Module (Optional) - Sentiotec Wave.com4 Montageanleitung

Instructions for assembly and use

7.2.0 HUMIDITY MODULE (OPTIONAL)

Supply
Power consumption
Fuse
Ambient conditions
Casing
Fastening
Dimensions: L x W x D
Weight

7.3.0 COLOUR MODULE (OPTIONAL)

Supply
Power consumption
Fuse
Ambient conditions
Casing
Fastening
Dimensions: L x W x D
Weight
WE DO IT FIRST.
3-pole with L1, N ,PE
12 V= / ~20 mA normal operation (~0.3 W)
4 A slow for the ventilator outlet
0 ° C – 50 ° C, max. 95 % rel. humidity, not condensi ng
Open board in casing of power unit
Board via M3 bolts on carrier plate
80 x 60 x 25 mm
~100 g unpacked
3-pole with L1, N ,PE
Only in the case of lighting, max. 4 x 60 W
Unfused or via 4 A slow when supplied by humidity module
above
0 ° C – 50 ° C, max. 95 % rel. humidity, not condensi ng
Open board in casing of power unit
Board via M3 bolts on carrier plate
100 x 60 x 25 mm
~150 g unpacked
55 /228
