UL Satisfaction Ratings
Depending on the number of fiber amplifiers and
displacement sensor amplifier units connected to
the WI180C-IOA00, the total load current of the out
put and the ambient temperature are limited as follows:
When power is supplied from a master unit of the
fiber amplifier/the displacement sensor amplifier unit
WLL180T/KTL180/WLL80 series: up to 2 units
Input: 12 ... 24 V DC, Max. 0.14 A Class 2
Output: 12 ... 24 V DC, Max. 0.1 A Class 2
Maximum Ambient Temperature 55 °C
WLL180T/KTL180 series: up to 3 units
Input: 12 ... 24 V DC, Max. 0.14 A Class 2
Output: 12 ... 24 V DC, Max. 0.1 A Class 2
Maximum Ambient Temperature 55°C
WLL180T/KTL180/WLL80 series: up to 5 units
Input: 12 ... 24 V DC Max. 0.14 A Class 2
Output: 12 ... 24 V DC, Max. 0.1 A Class 2
Maximum Ambient Temperature 50°C
WLL180T/KTL180 series and AOD1 series: up to 8 units
Input: 12 ... 24 V DC, Max. 0.14 A Class 2
Output: 12 ... 24 V DC, Max. 0.1 A Class 2
Maximum Ambient Temperature 50 °C
WLL180T/KTL180/WLL80 series and AOD1 series: up to 8 units
Input: 12 ... 24 V DC, Max. 0.14 A Class 2
Output: 12 ... 24 V DC, Max. 0.1 A Class 2
Maximum Ambient Temperature 45°C
WLL180T/KTL180 series: up to 16 units
Input: 12 ... 24 V DC, Max. 0.08 A Class 2
Output: 12 ... 24 V DC, Max. 0.04 A Class 2
Maximum Ambient Temperature 45°C
WLL180T/KTL180/WLL80 series: up to 16 units
Input: 12 ... 24 V DC, Max. 0.08 A Class 2
Output: 12 ... 24 V DC, Max. 0.04 A Class 2
Maximum Ambient Temperature 40°C
When power is supplied from WI180C-IOA00
WLL180T/KTL180/WLL80 series: up to 2 units
Input: 12 ... 24 V DC, Max. 0.284 A Class 2
Output: 12 ... 24 V DC, Max. 0.1 A Class 2
Maximum Ambient Temperature 55 °C
WLL180T/KTL180 series: up to 3 units
Input: 12 ... 24 V DC, Max. 0.296 A Class 2
Output: 12 ... 24 V DC, Max. 0.04 A Class 2
Maximum Ambient Temperature 55 °C
WLL180T/KTL180/WLL80 series: up to 3 units
Input: 12 ... 24 V DC, Max. 0.276 A Class 2
Output: 12 ... 24 V DC, Max. 0.04 A Class 2
Maximum Ambient Temperature 50 °C
One WLL180T/KTL180/WLL80 series and one AOD1 series.
Input: 12 ... 24 V DC, Max. 0.292 A Class 2
Output: 12 ... 24 V DC, Max. 0.1 A Class 2
Maximum Ambient Temperature 50°C
