3.3
Gasflussplan
3.3.1
Atemsystem
Nr.
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
Gebrauchsanweisung
Bezeichnung
Frischgas (O
, Air, N
2
CO
-Absorber
2
Umschaltung zwischen maschineller Beatmung und Manuell / Spontan
Anästhesiegas-Aufnahmesystem
Anästhesiegas-Fortleitungsventil
APL-Ventil
Atembeutel
PEEP/Pmax-Ventil
Patientengas-Messmodul (Hardwarevariante)
Exspirationsventil
Exspiratorische Druckmessung
Atemwegsdruck-Manometer (Option)
Patient
Exspiratorischer Flowsensor
Inspiratorischer Flowsensor
Inspirationsventil
Inspiratorische Druckmessung
Inspiratorischer O
-Sensor (Hardwarevariante)
2
Kolbenventilator
Frischgas-Entkopplungsventil
|
Atlan A300, A300 XL, A350, A350 XL SW 2.0n
O) und Anästhesiegas
2
Übersicht
49
