No. Component
1 Display (optional)
2 Control unit
3 Wireless display (optional)
4 Inverter
5 Battery charger
6 House battery 1
Connection variant B
fig.  on page 6
No. Component
1 Display (optional)
2 Control unit
3 Wireless display (optional)
4 Charge controller
5 Solar panel
6 Solar panel
Connection variant C
fig.  on page 7
No. Component
1 Display (optional)
2 Control unit
3 Wireless display (optional)
4 Charge controller
5 Solar panel
6 Solar panel
7 Battery charger
8 Inverter
6 Operation
1. Switching the battery monitor on or off:
fig.  on page 8
2. Displaying the battery voltage and current:
fig.  on page 8
3. Activate the automatic mode by tapping the
16
No. Component
7 House battery 2
8 Additional 12 V devices
9 12 V fridge or oven
10 Split-charge relay
11 Starting battery
12 Alternator
No. Component
7 House battery
8 Additional 12 V devices
9 12 V fridge or oven
10 Split-charge relay
11 Starting battery
12 Alternator
No. Component
9 House battery 1
10 House battery 2
11 Additional 12 V devices
12 12 V fridge or oven
13 Split-charge relay
14 Starting battery
15 Alternator
