2.9 Pure Blends with Incorrect Component Ratios
The Ultima ID Pro™ has the ability to detect blend ratios that have been altered by contamination. As stated in section 2.8 Pure
Blend Refrigerants, the blends that can be Identified and Analyzed are R134a, R22, HC (Hydrocarbons), R404A, R407C and
R410A. If one of the multi-component refrigerant blends has incorrect component ratios, it will display as shown below in (Figure
17). To see the component concentrations, press the 'MORE' button (Figure 18). Refer to section 2.10 Print the Test Results &
Channel Data to print.
2.10 Measuring Air
The Ultima ID Pro™ offers the ability to measure the presence of Air independently during every test. The built in oxygen sensor
will display the percentage of Air in all Identified or Identified and Analyzed refrigerants if there is Air in a system or cylinder. The
image below in (Figure 19) portrays how the LCD will display Air if detected. Pressing 'MORE' will display the purity of the refriger-
ants which were detected (Figure 19a).
NOTE: Air is measured independently from refrigerant! You can have 100% pure refrigerant with a percentage of Air in a system
or tank. The presence of Air will display on the initial results screen and on every printed test.
2.11 Printing the Test Results & Channel Data
The Test Results and Channel Data can be printed after every test is completed. Pressing 'PRINT' on the bottom of the screen
will print the test results for all Analyzed Refrigerants. The screen in (Figure 20) will display during printing. If printing Identified
or 'Unknown Refrigerants", pressing 'PRINT' will allow you to print the Channel Data from the test. (Figure 21) will display during
Channel Data printing.
Once printing is complete, carefully tear off the printout and press 'BACK' to return to the previous screen. Additional printouts may
be made following the same procedure. To exit the test, press the 'DONE' button. (Figures 22, 23, & 24) show sample printouts
