2 ULTIMA ID PRO™ OPERATION

2.1 First Use

The Ultima ID Pro™ has a built in Lithium Iron Phosphate battery. Prior to first use charge the battery for a minimum of 2 hours
with the included AC Power Supply. If a power outlet is accessible you may also use the AC Power Supply to power the unit. The
analyzer will function and charge the battery while the AC Power Supply is connected.
2.2 Turning On the Unit
Press the left, soft key, 'POWER' button. The splash screen shown in (Figure 1) will appear followed immediately by the screen in
(Figure 2). If you wish to adjust factory settings press 'SET' and refer to section 3 Maintenance & Troubleshooting. If you do not
need to adjust the settings wait for the screen in (Figure 3) to appear. Connect the sample hose to the analyzer and wait approxi-
mately 30 seconds for the unit to warm up. Once the analyzer warms up you are ready for Calibration.
2.3 Calibration
The supplied sample hose needs to be connected to accomplish proper Calibration. Verify the Sampling Hose assembly
is connected to the analyzer and making sure it is disconnected from any refrigerant source before Calibration. When
you first turn the unit on an Air Calibration will be required; additional Air Calibrations are only required periodically. A reminder to
perform air calibrate will appear when needed (Figure 4). Press 'CAL' to calibrate the machine. When calibrating, the unit will pull
fresh air into the sample cell via an internal pump. This fresh air purges any excess refrigerant and ensures accurate test results.
Calibration requires that the sample hose is disconnected from the refrigerant cylinder or air conditioning system and remains
connected to the instrument. (Figure 5) will display while the Air Calibration is occurring. Calibration will take approximately 130
seconds.
NOTE: In the unlikely event an 'Air Calibration Unstable' message is displayed as shown in (Figure 6) verify you are in a ventilate
area and there is no gas flowing near the air intake. Once you have verified both parameters, press 'RETRY' to complete another
calibration.
6
SOFTWARE VERSION
453- XXXX-XXXX
Figure 1
CONNECT HOSE
TO ANALYZER
AIR CALIBRATION
IS NEEDED NOW
1- DISCONNECT
HOSE FROM
SOURCE
2- PRESS CAL TO
START
OFF CAL
Figure 4
www.mastercool.com
TO CHANGE
SETTINGS OR
REPLACE PAPER
ROLL PRESS
SET
Figure 2
Figure 3
-
CALIBRATING -
- PROGRESS -
Figure 5
