for various test results.
Refrigerant
Analyzer
R22 = 100.0%
AIR = 0.0%
___________
(Date)
____________
(Technician)
___________
___________
Figure 22
NOTE: Care must be taken when tearing off the printed results to leave a clean edge. Tear the paper from RIGHT to LEFT to
avoid paper jams.
2.12 Channel Data Modelling
Channel Data Modelling is a unique feature to the Ultima ID Pro™. It allows the user to test refrigerants that the analyzer may not
already identify and "fingerprint" the data using the available channels. The channel data is available for Identified and "Unknown
Refrigerants."
Once you complete a test on an Identified Refrigerant (see list in section 2.8 Pure Refrigerants) or "Unknown Refrigerants", the
test results will display similar to (Figure 25) for Identified Refrigerants or (Figure 25a) for "Unknown Refrigerants." Once dis-
played, the analyzer will allow the user to print. Press the 'PRINT' button and the data will appear on the printout like (Figure 26).
This new feature allows the user to develop a "fingerprint" model for different refrigerants the Ultima ID Pro™ may not already
analyze. If the user tests a virgin tank of refrigerant at least 3 times and receives Channel Data that is consistent or within a close
range to one another, this data can be used as a "fingerprint" model of that particular refrigerant. This feature will allow the user to
have a guide to identify refrigerants not already established by the analyzer and increases the capabilities of the Ultima ID Pro™.
NOTE: This is not a guaranteed method for identifying refrigerants. Results will vary and some refrigerants may create inconsis-
tent data.
10
Refrigerant Refrigerant
Analyzer Analyzer
R410A = 100.0%
NON-CONDENSABLE
R125 = 50.0%
R32 = 50.0%
AIR = 0.0%
___________
___________
(Date)
(Date)
____________
____________
(Technician)
(Technician)
____________
___________
__________
___________
Figure 23
0.0% AIR
REFRIGERANT
R32
PURITY UNKNOWN
PRINT DONE
Figure 25
0.0% AIR
UNKNOWN
REFRIGERANT
PRINT DONE
Figure 25a
Figure 24
Refrigerant
Analyzer
R32
Purity Unknown
Channel Data
F01: #
F02: #
F03: #
F04: #
F05: #
F06: #
F07: #
F08: #
F09: #
F10: #
F11: #
F12: #
Figure 26
