3.7 Air Sensor Low
In the event you receive an 'Air Sensor Low' message like (Figure 32) there is no need to discontinue use. This message is meant
to alert you that the built in oxygen sensor is depleting and will need to be replaced in the near future. If the analyzer you are
using is new and you believe you received this message in fault, first verify gas is not flowing into the analyzer and that you are in
a well ventilated area. Once you have verified both, press 'RECAL' to recalibrate the analyzer. If you have had the analyzer for a
few years the oxygen sensor may be near depletion. Pressing 'TEST' allows you to bypass the message and finish your testing.
The oxygen sensor is a consumable part and will eventually need to be replaced. After receiving this message plan on contacting
Neutronics Inc to schedule a service appointment.

3.8 Error Messages

In the unlikely event that an "Error" message is displayed on the screen, power off the unit, take it to a location outside of the shop
environment where fresh air is available and turn the unit back on. If the "Error" message reappears, refer to the help screens on
the instrument or contact our service department for assistance.
THE BATTERY
VOLTAGE IS LOW
RECHARGE THE
BATTERY SOON OR
USE 12V POWER
SUPPLY
OFF IGNORE
Figure 31
AIR SENSOR LOW
DISCONNECT HOSE
FROM TANK
AND PRESS RECAL
RECAL TEST
Figure 32
