CNX Controller
Functions and test
Functions on the controller
CNX
CNX
64
150
1
Switch ON / OFF
2
SD card slot
3
Restart WLAN AP
4
Reset data
5
WLAN antenna
System test
CNX
CNX
64
150
1
Switch on the device
2
wait 10 seconds
3
Device ready for operation
when POWER LED
lights green and
CNX LED flashes red
4
Function test showers (piezo switch)
5
Send commissioning request
to CONTI
