Topology – ONLY valid for CONPRIMUS and lino PRIMUS
CNX Converter
CONO210012
J-Y(St)Y 2x2x0,8 mm
Lay connecting cables in flush-
mounted empty conduit
(max. 100 m from power sup-
ply unit to last shower / fitting;
max. 10 showers / fittings per
line segment)
* Mounting recommendations
Washroom ladies
max. 600 mm
lino PRIMUS Stand fittings
CONTI Sanitärarmaturen GmbH | Hauptstraße 98 | 35435 Wettenberg | Deutschland | Tel. +49 641 98221 0 | Fax +49 641 98221 50 | info@conti.plus
www.conti.plus | Druckfehler und Irrtümer sowie technische und maßliche Änderungen vorbehalten. | Errors and technical changes remain reserved.
Shower room ladies
1 2
Shower panels CONPRIMUS
Shower room men
3 4 5
Washroom men
CNX Converter flush-mounted
CONO211012
. . .
10
max. 10 per
Line segment
900 mm*
