Safety-related information

– Before using this product, carefully read these instructions for use and those
of the associated products.
– Strictly follow the instructions for use. The user must fully understand and
strictly observe the instructions. Use the product only for the purposes
specified in the intended use section of this document.
– Do not dispose of the instructions for use. Ensure that they are stored and
used appropriately by the product user.
– Only trained and competent users are permitted to use this product.
– Do not use a faulty or incomplete product. Do not modify the product.
– Notify Dräger in the event of any component fault or failure.
– Comply with all local and national rules and regulations associated with this
product.
– Only trained and competent personnel are permitted to inspect, repair and
service the product. Dräger recommend a Dräger service contract for all
maintenance activities and that all repairs are carried out by Dräger.
– Use only genuine Dräger spare parts and accessories. Otherwise, the
proper functioning of the product may be impaired.
– Identical parts and features have a common description, connection-specific
differences are marked in bold.
2

Conventions in this document

2.1

Meaning of the warning notices

The following warning notices are used in this document to alert the user to
potential hazards. The meanings of the warning notices are defined as follows:
Warning sign Signal word
WARNING
CAUTION
Instructions for use |
Dräger FPS 7000
Classification of the warning notice
Indicates a potentially hazardous situa-
tion. If not avoided, it could result in
death or serious injury.
Indicates a potentially hazardous situa-
tion. If not avoided, it could result in
physical injury. It may also be used to
alert against unsafe practices.
Warning sign Signal word
NOTICE
3

Description

3.1

Product overview

– Full face mask (see figure A1 on fold-out page)
– Mask/helmet combination with S-fix/Q-fix mask/helmet adapter (see
figure A2 on fold-out page)
– Mask/helmet combination with X-fix mask/helmet adapter (see figure A3 on
fold-out page)
– Mask connections (see figure A4 on fold-out page)
1 Mask body
3 Adjuster buckle
5 Upper visor frame
7 Inner mask
9 Lower visor frame
11 1)
Exhalation valve cover
13 S-fix/Q-fix mask/helmet adapter 14
15 Neck guard
17 Helmet
19 Connector
21 O-ring
23 Inhalation valve
25 Exhalation valve disc
Safety-related information
Classification of the warning notice
Indicates a potentially hazardous situa-
tion. If not avoided, it could result in
damage to the product or environment.
2 Carrying strap
4 Head harness
6 Visor
8 Control valve
10 Cap
12 Visor
Chin strap
16 Full face mask fastener
(fastening plate and adapter
pocket)
18 X-fix mask/helmet adapter
20 Speech diaphragm
22 Clamping ring
24 Exhalation valve seat
26 Button
