Connection Assignment Of The Key Switches; Pin Assignment Of The Connectors/Plugs; Commissioning And Maintenance; Commissioning - Ssp Simplifier Box 253 Betriebsanleitung

Simplifier BOX 253
- 3 positions
- illuminated
- momentary
- Contact 2x NO
- without labeling
- 3 positions
- illuminated
- momentary
- Contact 2x NO
- individual labeling
- 3 positions
- illuminated
- toggle
- Contact 2x NO
- without labeling
- 3 positions
- illuminated
- toggle
- Contact 2x NO
- individual labeling

4 .35 Connection assignment of the key switches

Connection assignment Design
- 3 positions
- toggle
- Contact 2x NO
- without labeling
- 3 positions
- toggle
- Contact 2x NO
- individual labeling
- 2 positions
- momentary
- Contact 2x NO
- without labeling
- 2 positions
- momentary
- Contact 2x NO
- individual labeling
34
Connection assignment
SG SP-X-88-000-68
SN SP-X-88-000-76
SH SP-X-88-000-69

4 .4 Pin assignment of the connectors/plugs

SO SP-X-88-000-77
Male connector M12 5-pin
Pin 1: brown
Item Item
Pin 2: white
code number
Pin 3: black
KB SP-X-88-000-85
Male connector M12 8-pin
KF SP-X-88-000-91
Pin 1: white
Pin 2: brown
Male connector M12 12-pin
KC SP-X-88-000-86
KG SP-X-88-000-92
Pin 1: brown
Pin 2: blue
Pin 3: white

5 . Commissioning and Maintenance

5 .1 Commissioning

5 .11 Function Test

The Simplifier BOX and all installed switches, buttons and display elements must be checked
before each commissioning. Safety elements (e.g. emergency stop buttons) must be tested
with regard to their safety function. Ensure the following before you start:
• The cable entries and connections are not damaged
• The housing and the installed switches, buttons and display elements are not damaged
• Emergency stop buttons:
- Mechanical inspection: Emergency stop engages when actuated
- Electrical inspection: Machine stops/switches off when actuated
Design
- 2 positions
- toggle
- Contact 2x NO
- without labeling
- 2 positions
- toggle
- Contact 2x NO
- individual labeling
Socket plug M12 5 Pin
2 1
5
3 4
Pin 4: blue
Pin 5: gray
Socket plug M12 8 Pin
2 1
3 7
8
4 6
5
Pin 3: green Pin 5: gray
Pin 4: yellow Pin 6: pink
Socket plug M12 12 Pin
2 1
3 9
10
11 12
4 8
5 6 7
Pin 4: green Pin 7: black
Pin 5: pink Pin 8: gray
Pin 6: yellow Pin 9: red
Warning!
Damaged or defective devices or components must not be put into operation!
Item Item
code number
KD SP-X-88-000-87
KH SP-X-89-000-93
1 2
5
4 3
1 2
7 3
8
6 4
5
Pin 7: blue
Pin 8: red
1 2
9 3
10
12 11
8 4
7 5
6
Pin 10: purple
Pin 11: gray/pink
Pin 12: red/blue
EN
