2 .6 Connection variants

Figure Compo- Design
nent
Cover
Cover - Thread M16
- Color yellow
- Thread M16
- Color anthracite
Cable connection
Cable - Thread M16
connection - Color black
Male connector M12
Male - Wired with open ends
connector - Wire length 250 mm
M12, 5-pin - Male connector
Male - Wired with open ends
connector - Wire length 250 mm
M12, 8-pin - Male connector
Male - Wired with open ends
connector - Wire length 250 mm
M12, - Male connector
12-pin
Pigtail cable with male connector M23
Pigtail cable - Cable length 20 cm
19-pin - Male connector M23,
M a l e 19-pin
connector - Cable with open end
M23
Socket plug M12
Socket - Wired with open ends
plug - Wire length 250 mm
M12, 5-pin - Socket plug
Socket - Wired with open ends
plug - Wire length 250 mm
M12, 8-pin - Socket plug
Socket - Wired with open ends
plug - Wire length 250 mm
M12, 12-pin - Socket plug
Pigtail cable with socket plug M23
Pigtail cable - Cable length 20 cm
19-pin - Socket plug
Socket
plug M23 - Cable with open end
EN
Item
code
AY
AG
B0
C0
M12, 5-pin
D0
M12, 8-pin
E0
M12, 12-pin
G0
H0
M12, 5-pin
I0
M12, 8-pin
J0
M12, 12-pin
L0
M23, 19-pin

2 .7 Item code

Item
number
SP-N-88-001-73
SP-N-88-001-74
SP-X-88-001-27
B-H0X-XX-XX-XX-XX-XX-XXX-XXX-XXX-XXX
SP-X-88-001-58

2 .8 Special design types

For special design types, that are not listed in the type code in „2.7 Item code", the above
SP-X-88-001-59
and following information is accordingly applicable if they correspond to the standard design.
SP-X-88-001-60
SP-X-88-001-32
SP-X-88-001-63
SP-X-88-001-64
SP-X-88-001-65
SP-X-88-001-37
Simplifier BOX 253
Housing Simplifier BOX
Housing color, number of buttons
Button position 1
Button position 2
Button position 3
Button position 4
Button position 5
Connection 1
Connection 2
Connection 3
Connection 4
