Simplifier BOX 253

2 .9 Technical data

2 .91 Housing

Material
Housing
Ambient conditions
Storage temperature
Operating temperature
Protection class
Mechanical data
Bottom of the housing dimensions (W x H x D) 253 x 40 x 44 mm / 9.96 x 1.57 x 1.73 in
Maximum housing dimensions (W x H x D)
(without buttons)
Installation openings for operating elements Ø 22.5 mm / Ø 0.89 in
Electrical data
Utilization category
Operating voltage
Rated voltage
Connection
24
PC and ABS
Max. -20°C...65°C / -4°F...149°F
Max. -20°C...65°C / -4°F...149°F
IP65
253 x 42 x 44 mm / 9.96 x 1.65 x 1.73 in
DC13
24 VDC ±5%
Max. 2 A
Spring-loaded terminals or M12 plugs

2 .92 Emergency stop buttons

Item code
General data
Approvals
Torque (mounting nut)
Installation opening
Electrical data
Rated operating voltage Ue
Rated operating current Ie
Switch type:
- Normally open contact (NO)
- Normally closed contact (NC)
- LED
Vertical resistance NO
Vertical resistance NC
Bounce time NO
Bounce time NC
NC contact direct opening
Switching capacity
Thermal continuous current
Lighting
Mechanical service life
Electrical service life (rated load)
Unlocking
Connection type
Number of pins
Wire cross-section:
- Single-wire
- Fine-wire
- Fine-wire (with wire end ferrule
with plastic collar)
- Fine-wire (with wire end ferrule
without plastic collar)
Stripping length
Safety data
B10d value
EA EB
CE, TÜV Süd
1.3...1.9 Nm
Ø 22.3 mm / Ø 0.88 in
24 V
0.25 A
- -
2 2
- 1
- <50 mOhm (AU)
<50 mOhm (AU)
- <10 ms
<10 ms
According to EN60947-5-1, Annex K
10 Ie
5 A
None LED None
50,000 cycles
50,000 cycles
Clockwise and counterclockwise rotation
Spring-loaded terminals
6
0.08...0.5 mm 2 / 28...20 AWG
0.08...0.5 mm / 28...20 AWG
2
0.25 mm² / 24 AWG
0.25 mm² / 24 AWG
5...6 mm / 0.2...0.24 in
250,000
EC
1
2
-
