2 .95 Selector switch 2 positions, without labeling

Item code
General data
Approvals
Number of switching positions
Switching mode
Labeling
Torque (mounting nut)
Installation opening
Electrical data
Rated operating voltage Ue
Rated operating current Ie
Switch type:
- Normally open contact (NO)
- Normally closed contact (NC)
- LED
Vertical resistance NO
Vertical resistance NC
Bounce time NO
Bounce time NC
NC contact direct opening
Switching capacity
Thermal continuous current
Lighting
Mechanical service life
Electrical service life (rated load)
Connection type
Number of pins
Wire cross-section:
- Single-wire
- Fine-wire
- Fine-wire (with wire end ferrule
with plastic collar)
- Fine-wire (with wire end ferrule
without plastic collar)
Stripping length
26
SA SW SC SD
CE
2
Momen- Toggle Momen- Toggle Momen-
tary tary
Without
1.5...1.9 Nm
Ø 22.3 mm / Ø 0.88 in
24 V
0.25 A
1 1
1 1
- 1
<20 mOhm
<20 mOhm
<10 ms
<10 ms
According to EN60947-5-1, Annex K
10 Ie
5 A
None LED
1,000,000 cycles
1,000,000 cycles
Spring-loaded terminals
6
0.08...0.5 mm / 28...20 AWG
2
0.08...0.5 mm / 28...20 AWG
2
0.25 mm² / 24 AWG
0.25 mm² / 24 AWG
5...6 mm / 0.2...0.24 in

2 .96 Selector switch 3 positions, without labeling

SS ST Item code
General data
Approvals
Number of switching positions
Toggle Switching mode
tary
Labeling
Torque (mounting nut)
Installation opening
Electrical data
Rated operating voltage Ue
Rated operating current Ie
Switch type:
- Normally open contact (NO)
2 - Normally closed contact (NC)
- - LED
1
Vertical resistance NO
Vertical resistance NC
-
Bounce time NO
Bounce time NC
-
NC contact direct opening
-
Switching capacity
Thermal continuous current
Lighting
Mechanical service life
Electrical service life (rated load)
Connection type
Number of pins
Wire cross-section:
- Single-wire
- Fine-wire
- Fine-wire (with wire end ferrule
with plastic collar)
- Fine-wire (with wire end ferrule
without plastic collar)
Stripping length
SE SF SG
CE
3
Momentary Toggle Momentary
Without
1.5...1.9 Nm
Ø 22.3 mm / Ø 0.88 in
24 V
0.25 A
2
-
-
<20 mOhm
-
<10 ms
-
-
10 Ie
5 A
None
1,000,000 cycles
1,000,000 cycles
Spring-loaded terminals
6
0.08...0.5 mm 2 / 28...20 AWG
0.08...0.5 mm / 28...20 AWG
2
0.25 mm² / 24 AWG
0.25 mm² / 24 AWG
5...6 mm / 0.2...0.24 in
SH
Toggle
2
-
1
LED
