Simplifier BOX 253

3 .32 Install the button/indicator light

1 .) Position the button/indicator light in the housing opening.
2 .) Make sure that the positioning cams are in the positioning slots in the housing.
3 .) Attach the fastening nut and tighten it with the mounting wrench.

3 .33 Install the selector switch

1 .) Position the selector switch in the housing opening.
2 .) Make sure that the positioning cams are in the positioning slots in the housing.
3 .) Attach the fastening nut and tighten it with the mounting wrench.
30

3 .34 Install the key switch

1 .) Position the key switch in the housing opening.
2 .) Make sure that the positioning cams are in the positioning slots in the housing.
3 .) Attach the fastening nut and tighten it with the mounting wrench.

3 .4 Install the blind cover

1 .) Position the blind cover in the threaded opening.
2 .) Tighten with the Allen key (size 5 mm).
