12 Maintenance and cleaning

This product is maintenance-free. Repairs are only to
be done by trained professionals.
Dimming actuator
The device is provided with two internal device
fuses for protecting the triac from greater
current loads. If the device becomes
overloaded and a fuse is blown, it can be
replaced by a technician!
Disconnect the mains power before removing
the device (switch the circuit breaker off)! Work
on the 230V network is only permitted by
qualified electricians (in accordance with VDE
0100).
Replace fuses with same type fuses (micro-
fuse 5 x 20 mm, 2.5 A slow)!

13 Other notes on operation

Applicable for HM-LC-Dim2T-SM: If the device
reaches too high a temperature during operation (due
56
to insufficient air circulation at high load, for example),
the load will first of all be reduced by lowering the
brightness. If the overtemperature persists, the load
will be disconnected.
If the actuator is operating via the HomeMatic
central control unit (CCU), please note that the
central control unit will not be informed in the
event of a load failure.
14 Technical specifications
Radio frequency:
Typ. outdoor range:
Power supply:
Standby consumption:
Degree of protection:
Protection class:
Housing:
Housing color:
868.3 MHz
300 m
230 V / 50 Hz
0.5 W
HM-LC-Dim2L-SM: 0,8 W
HM-LC-Dim2T-SM: 1 W
IP65
II
PC
Light gray
