the device. Make sure that the specified wiring and
wire cross-sections are used when connecting to
device terminals.
Switch actuator:
Follow all technical specifications, especially the
maximum permitted switching capacity of the relay and
type of consumer to be connected, before connecting
the consumer! All load specifications refer to resistive
loads!
Blind actuator:
The actuator is only suitable for 230V a.c. motors!
Never connect three-phase a.c. motors or d.c. motors!
If motors are connected to the output in parallel
with the actuator, make sure to observe the motor
manufacturer's specifications. The motors can be
damaged otherwise. Use only blinds or shutters with
limit switch (mechanical or electronic)!
Check the limit switch for the connected motors for
proper adjustment before starting the blind actuator!
Use only mains power capable buttons and wires for
connecting to button inputs!
36
Dimming actuator:
Make sure to observe the applied load! The dimmer is
only suitable for light bulbs and for low voltage
NV halogen lamps with magnetic transformers!
The devices are not intended to be isolated. The load
is not electrically isolated from the mains.
Fuse every transformer on the primary side according
to the manufacturer's specifications when working with
conventional transformers.
Use only safety transformers that conform with
DIN EN 61558-2-6 (VDE 0570 part 2-6).
3

Function

The actuators control connected consumers based on
the radio commands received. Commands are sent
out by actuating buttons, remote operations or from a
software interface. In addition, it is possible to control
actuators with sensors that are taught.
The sensors send (like a button) a command when
an event occurs. More information is provided in the
instructions for the respective sensor.
