Other interfering sources can be caused by switching
operations, electrical motors or defective electrical
devices.
The range of transmission within buildings can
greatly deviate from open air distances.
Besides the transmitting power and the
reception characteristics of the receiver,
environmental influences such as humidity in
the vicinity and local structures also play an
important role.
Hereby eQ-3 Entwicklung GmbH, declares that
this device conforms with the essential require-
ments and other relevant regulations of Directive
1999/5/EC.
The full declaration of conformity is provided under
www.HomeMatic.com.
44
6

Installation

The surface-mount actuators are suitable for installing
outdoors and in humid rooms because of the
increased degree of protection.
Remove the transparent housing cover for mounting
and installing. The holes for fastening to the wall are
visible underneath.
In order to access the connection terminals, remove
the gray cover plate.
The installation of the described actuators is shown
in the following connection diagrams. Connect the
actuators to L and N for the supply. Run the channel
circuit to the consumer.
