7.2 Teaching-in

Please read this section completely before starting
with any teaching-in!
Teaching-in requires that both devices to be connected
are put into teach mode and the desired channel must
be selected for training.
The surface-mount actuators have no special teach
button.Teaching a certain actuator channel requires
pressing and holding the respective channel button
(one of the two buttons ▲ or ▼ for the blind
actuators).
Teach mode is indicated by the device LED flashing
continuously.
If no teaching occurs, teach mode is automatically
ended after 20 seconds. If other devices are in teach
mode, these are taught.
8

Operation

After teaching, simple operating functions are available
using the taught control elements.
52

8.1 Switching actuator

Depending on the control elements that have been
taught, the switch actuator can be controlled in two
button ON/OFF mode or in toggle mode.

8.2 Blind actuator

Depending on the control elements that have been
taught, the blind actuator can be controlled in two
button UP/DOWN mode or in toggle mode (UP/STOP/
DOWN/STOP).

8.3 Dimming actuator

Depending on the learned operating element, the
dimmer can be used in two button ON/OFF operation
or in toggle operation ON/OFF with a brief press on
the button and brighten/dim with a longer press of the
button.
9

Resetting to the initial state

In order to reset the actuator to factory status, switch
the device to teach mode with the (first) channel button
53
