HM-LC-Sw1-SM
Relay:
Switching capacity:
Dimensions (H x W x D):
HM-LC-Sw4-SM
Relay:
Switching capacity:
Dimensions (H x W x D):
HM-LC-Bl1-SM
Relay:
Switching capacity:
Operating temperature:
Dimensions (H x W x D):
HM-LC-Dim2L-SM
Connection power:
Dimensions (H x W x D):
58
Change-over
(potential-free contacts)
16 A (resistive load)
90 x 115 x 55 mm
4 change-over
(potential-free contacts)
16 A (resistive load)
121 x 171 x 55 mm
1 normally open,
1 change-over
(potential-free contacts)
4 A motor load
-10 to +55 °C
115 x 160 x 55 mm
2 x 25–500 VA
121 x 171 x 55 mm
HM-LC-Dim2T-SM
Connection power:
Dimensions (H x W x D):
Subject to technical changes.
Instructions for disposal
Do not dispose off the device as part of
household garbage! Electronic devices are to
be disposed ofin accordance with the
guidelines concerning electrical and electronic
devices via the local collecting point for old
electronic devices.
The CE sign is a free trade sign addressed
exclusively to the authorities and does not
include any warranty of any properties.
2 x 300 VA
171 x 55 x 121 mm
