Function and device overview

3 Function and device overview
The Homematic IP DIN-Rail Adapter can be used for DIN
rail installation of your Homematic IP Multi IO Box.
The Multi IO Box is easily mounted to the adapter by
means of the mounting suspensions and the supplied
screws. The DIN-rail adapter together with Multi IO Box
can then be snapped on an existing DIN-rail.
Device overview (see figure 1):
(A)
Mounting suspensions for Multi IO Box
(B) Screw holes for Multi IO Box
(C)
Bracket for DIN-rail
(D)
Spring latch for DIN-rail
4

General information

This adapter is part of the smart home system
Homematic IP and can be used for DIN-rail installation
of a Homematic IP Multi IO Box. All current technical
documents and updates are provided at www.eQ-3.de.
eQ-3 AG hereby declares that this device complies with
the essential requirements and other relevant regulations
of Directive 1999/5/EC. You can find the full declaration
of conformity at www.homematic-ip.com.
