DIS2116

5.7 RS485 interface (Terminal block K1)

The DIS2116 is the master for the connection with the digital load cells (C16i,
measurement chain).
COM5
Fig. 5.4:
Connection positions (back of device); assignment, see page 14

5.8 Terminal block K1 assignments

The terminal block K1 has the following signals:
− Supply voltage input
− Supply voltage load cell output
− RS485 4−wire load cell interface
− CAN load cell interface (dependent on load cell) for future applications
A2540-1.1 en/de
COM2
COM3
COM4
Terminal block K1
PS2 USB
15
HBM
