Mounting Base / Mounting Kit - HBK Z6FD1 Montageanleitung

9.8

Mounting base / mounting kit

Dimensions (in mm; 1 mm = 0.03937 inches)
for E 5 kg (Z6/ZPU/200KG) ... 500 kg (Z6/ZPU/500KG)
max
View from below
28
Load application via:
Z6/...KG/ZPL; Z6/...KG/ZEL ; Z6/...KG/ZK
A
79
82±0.1
155
200
Tightening torque M
23 N⋅m at 200 kg
;
45 N⋅m at 500 kg
22.5
:
A
Z6
ACCESSORIES
