Important
Load must not be applied to the side where the cable connection is located, as this would
cause a force shunt.
The load must act as accurately as possible in the direction of measurement. Torsional
moments, eccentric loads and lateral or side forces cause measurement errors and can
permanently damage the load cell. Catch such interference effects, e.g. using lateral stay
bars or guide rollers, but ensure that these elements do not absorb any load or force
components in the direction of measurement (force shunt which will in turn lead to mea­
surement errors).
To minimize error effects from load application, HBM offers different load application
elements, according to the mounting conditions:
S
Pendulum bearing ZPL
S
Knuckle eyes ZGWR
S
Force feedback ZRR (for maximum capacities 5kg ... 200 kg)
S
Rubber-metal bearing ZEL
S
Cone/conical pan ZK
S
Oscillating loading foot PCX (for maximum capacities 5kg ... 500 kg)
S
Oscillating loading foot ZFP (for maximum capacities 5kg ... 200 kg)
S
Oscillating loading foot ZKP (for maximum capacities 5kg ... 200 kg)
S
Mounting base / mounting kit ZPU Z6/ZPU/200KG (for maximum capacities 5 kg ...
200 kg)
Z6/ZPU/500KG (for maximum capacity 500 kg)
8
MECHANICAL INSTALLATION
