6.6
Register Überwachungsfunktionen
Register
Beschreibung
Überwachungsfunktionen (Register 2000...2050)
2000
2001
Status
Messstromwandler
2002
2003
Reload-Speicher
2014
Ein-/Ausgang „Q"
Reload-Speicher
2015
Ausgang „M+"
6.7
Register Status-Informationen
Register
Beschreibung
Status-Informationen (Register 3000...3999)
3000
Test-Status
3001
Status Eingang „I"
3002
Status Ein-/Ausgang „Q"
3005
Status Ausgang „Q"
3006
Status Ausgang „M+"
Zustand Speicher aktiv
3009
Ein-/Ausgang „Q"
Zustand Speicher aktiv
3010
Ausgang „M+"
Zustand Speicher inaktiv
3013
Ein-/Ausgang „Q"
Zustand Speicher inaktiv
3014
Ausgang „M+"
Format
Bytes
CT1
UINT16
2
CT2
UINT16
2
CT3
UINT16
2
CT4
UINT16
2
UINT16
2
UINT16
2
Format
Bytes
UINT16
2
UINT16
2
UINT16
2
UINT16
2
UINT16
2
UINT16
2
UINT16
2
UINT16
2
UINT16
2
LINETRAXX® SmartDetect RCMS410
Eigen
Werte / Einheit / Kommentar
schaft
RO
0 = OK
RO
1 = Kurzschluss
RO
2 = Unterbrechung
RO
RO
0 = Reload-Speicher inaktiv
1 = Reload-Speicher aktiv
RO
Eigen
Werte / Einheit / Kommentar
schaft
0 = kein aktiver Test
RO
1 = Test mit T/R-Taste aktiv
2 = Test über Schnittstelle aktiv
0 = Eingang ist nicht betätigt
RO
1 = Eingang ist betätigt
0 = Eingang ist nicht betätigt
RO
1 = Eingang ist betätigt
2 = Ein-/Ausgang „Q" ist als Ausgang konfiguriert
Akueller Zustand des Ausgangs:
RO
0 = Ausgang inaktiv (kein Ereignis der Meldezuordungen ein-
getreten)
1 = Ausgang aktiv (mind. ein Ereignis der Meldezuordnungen
RO
eingetreten)
RO
Der letzte aktive Zustand (1) des Ausgangs wird bis zur nächsten
Modbusabfrage gehalten
RO
RO
Der letzte inaktive Zustand (0) des Ausgangs wird bis zur nächsten
Modbusabfrage gehalten
RO
