Transport Status
It is unlocked by hidden button or by putting it in charge. It is designed to minimize
battery consumption when RC is moved before becoming active at the end user.
EN
It is automatically unlocked by putting it on the charging platform.
KEYBOARD LAYOUT WITH FUNCTIONAL INDICATIONS
T1
POMPA 1
ON (white) = Active
OFF = Switched off
A1 Smart Winter Mode
ON (blu) = Active
OFF = Switched off
A2 Economy
ON (blu) = Active
OFF = Switched off
T4 hidden button to
activate/disactivate
transport mode
(t˃TonTrasporto)
T6 Economy
T9 lower
ON only if not affiliated
Otherwise OFF
- set-point change
- filtration change
- affiliation
T11 with optional bluetooth
Always OFF
-1st pressure→song starts
-double tap→previous son
T14 Slider volume level with
bluetooth
L14_1, L14_2, L14_3, L14_4, L14_5 (blue)
Minimum at L, maximum at R
T12 Solo AVRCP
Always OFF
-play/pause
Long press for entering into parameter edit
Legend symbology used for user interface
On
Flashing if not specified = from OFF to HI 1"ON 1" (blink)

REMOTE CONTROL FUNCTIONS

18
T2 BLOWER T3 PUMPA2
ON = Active ON = Active
OFF = Turned off OFF = Switched off
A3 Heater
ON (blue) = Resistence on
OFF = Resistence off
Blink = Suspended function
A4 Filtering
Blink = Suspended function
T5 hidden button to activate
NO_USER mode
T8 Light
Blink = ongoing colors cycle
ON = Fix colour
OFF = Switched off
T7 Filtration
Always OFF
Filtration programming
management (t˃TonFiltraz)
T10 Augmented
Always OFF
- set-point change
- filtration change
T13 with optional bluetooth
Always OFF
- change song
Display 7 segments 2 digit2
- Temperature viewing (default)
- Viewing/setting set-point
- Viewing/setting filtration cycles
- Battery level display
- Viewing ongoing charging cattery
- Viewing Alarms
NOTE:
FOR ALL BUTTONS, PRESSURE IS DETECTED WHEN
THE FINGER IS RELEASED, NOT WHEN TOUCHED.
FOR SLIDER (VOLUME SETTING) PRESSURE IS DE-
TECTED TOUCHED.
