TECHNICAL DATA

DATASHEET

Operating voltage
Nominal voltage
Power consumption
NMEA 2000® LEN
Protection class
Operating temperature
Flammability
Measurement range
LinkUp sensor cable length
NMEA 2000® cable length
LinkUp Sensor-side plug
Extension cable LinkUp-side plug
NMEA 2000® plug
Compliance
6 – 16.5 V
12 V (from NMEA 2000® network)
≤ 100 mA
2
IP X7 according to IEC60529 (when connected)
-30°C to 80°C
UL94-HB
100 – 900 °C
250 – 1650 °F
25 cm
25 cm
TE AMP Superseal 1.5 2 pins - Female
Housing: 282080-1
Terminals: 282403-1 (2x)
Sealing: 281934-2 (2x)
TE AMP Superseal 1.5 2 pins - Male
Housing: 282104-1
Terminals: 282404-1 (2x)
Sealing: 281934-2 (2x)
DeviceNet Micro-C M12 5 pins - Male
CE, Reach, RoHS, UL94, ISO 8846:1990
TECHNICAL DATA
B000942
