TECHNICAL DATA

LINKUP DATASHEET

Operating voltage
Nominal voltage
Power consumption
NMEA 2000® LEN
Protection class
Operating temperature
Flammability
Sensor cable length
NMEA 2000® cable length
NMEA 2000® plug

SENSOR DATASHEET

Operating voltage
Output Signal
Temperature measuring range
Pressure measuring range
Protection class
Sensor plug
Counterpart for sensor plug
6 – 16.5 V
12 V (from NMEA 2000® network)
≤ 100 mA
2
IP X7 according to IEC60529 (when connected)
-30°C to 80°C
UL94-HB
90 cm
25 cm
DeviceNet Micro-C M12 5-pins - Male
4.75 - 5.25V (Provided by the LinkUp)
PWM
-40°C to 150°C
0.5 to 10.5 bar
IP69k
Hirschmann 3way 1.2 SealStar FA Connector
Male
Hirschmann 3way 1.2 SealStar FA Connector Female
(872-858-541)
TECHNICAL DATA
