User manual / Bedienungsanleitung
2. Mounting the tonearm base
2.1 Mounting the tonearm base on the Clearaudio Performance DC or Ovation turntable
Please check that the correct tonearm base is mounted on your turntable (Pic. 2).
Please note that you will need an different tonearm base, if you want to mount the
in combination with the VTA-Lifter (Pic. 3).
If the wrong tonearm base is mounted, place the turntable on the edge of a table or similar surface,
so you have access to the tonearm base from below.
Remove the previous tonearm base by loosening the six M4 x 35mm screws with a hex wrench on
the bottom side of the clamping ring.
Exchange the tonearm base for the correct one and loosely tighten it, so the tonearm base is still
rotatable. Please make sure that the base sits perfect on the turntable.
Pic. 2: Tonearm base for Performance DC
& Ovation (Art. No. AC031-4)
Pic. 3: Tonearm base for Performance DC
& Ovation (Art. No. AC031-8)
Page / Seite 6
Without VTA-Lifter
To mount the tonearm without VTA-Lifter, you need the tonearm
base AC031-4 (Pic. 2)
With VTA-Lifter
To mount the tonearm in combination with VTA-Lifter, you need
the tonearm base AC031-8 (Pic.3).
Magnify
© clearaudio electronic GmbH, 2022-04
tonearm
