SAW BENCH
THE NUMBERS IN THE FOLLOWING TEXT
CORRESPOND WITH THE PICTURES AT
PAGE 2 + 3.
Caution! For your own safety, carefully read these
instructions for use before using the machine.
CONTENTS:

1. Technical specifications

2. Safety instructions

3. Assembly and adjusting instructions
4. Operation
5. Malfunctions
1. TECHNICAL SPECIFICATIONS
Voltage | 230 V~
Frequency | 50 Hz
Power input | 1500 W
No load speed | 4500/min
Saw blade dimensions | 254x15.9x3.2mm
Number of teeths | Z40
Measurements of bench | 635x430 mm
Dust extraction outlet | 30(20) mm
Weight | 22 kg
Lpa (sound pressure level) | 99.3 dB(A)
Lwa (sound power level) | 112.3 dB(A)
PRODUCT INFORMATION
Fig. A
1. Protective cap
2. Fence
3. Bench inlay
4. Mitre handle
5. Height handle
6. Measurement set-up for fence
7. On/off switch
8. Bench protractor for mitring
9. Workbench
10. Thermal protection
Check first whether or not the delivery has been
damaged by transport and/or whether all the parts are
present.
2. SAFETY INSTRUCTIONS
LIST OF SYMBOLS
The following pictograms are used in these instructions
and on the machine itself:
CE Conforms to the applicable European safety
standards
Danger of bodily injury or material damage.
4
Indicates electrical shock hazard.
Read the instructions
Keep bystanders at a distance
Immediately unplug the plug from the mains
electricity in the case that the cord gets damaged
and during maintenance
Wear eye and ear protectors
Faulty and/or discarded electrical or electronic
apparatus have to be collected at the appropriate
recycling locations.
Carefully read this manual before using the machine.
Make sure that you know how the machine functions and
how to operate it. Maintain the machine in accordance
with the instructions to make sure it functions properly.
Keep this manual and the enclosed documentation with
the machine.
ELECTRICAL SAFETY
When using electric machines always observe the
safety regulations applicable in your country to
reduce the risk of fire, electric shock and personal
injury. Read the following safety instructions and
also the enclosed safety instructions.
Always check that the power supply corresponds to
the voltage on the rating plate.
Replacing cables or plugs
Immediately throw away old cables or plugs when they
have been replaced by new ones. It is dangerous to insert
the plug of a loose cable in the wall outlet.
Using extension cables
• As a supply for this machine always use an unloaded
line and/or an extension cable with conductors of at
least 1,5 mm 2 and protected with a 16 A fuse. Be sure
that this extension cable is not longer than 20
metres.
• Only connect your machine and/or extension cable
to an earthed electricity mains.
• This machine can be switched to the single-phase
network (230 V/50 Hz). If you are in doubt about the
earth of the electricity provisions, consult an
electrician first.
Before use, remove the transport protection:
• Disassemble the bottom plate by loosening the 4
screws.
• Remove the transport protection below motor.
• The handles for height and mitre setting of the saw
blade are located in the transport protection inside
the machine.
• Reassemble the bottom plate.
