AGILITY Removal and Reattachment

Note: Safety locks must be in the UNLOCKED ( ) position to remove an AGILITY.
Warning: DO NOT remove the AGILITY while the individual is seated in the wheelchair.
1. UNLOCK ( ) the safety locks.

Cane Hardware Removal

Warning: DO NOT remove the cane hardware while the individual is seated in the wheelchair.
Note: Remove the AGILITY from the wheelchair before you remove the cane hardware. See "AGILITY Removal".
1. Loosen the bolt. The bolt should NOT disengage
from the adjustment cylinder.
ROHO AGILITY Quick Release Hardware Operation Manual
2. Pull up both of the latches to open them.
2. With your thumb against the bolt, pry the
pivoting band away from the adjustment
cylinder.
11
3. Use the handle to lift up the AGILITY and remove
it from the wheelchair.
AGILITY Reattachment:
To reattach the AGILITY on the wheelchair, follow
the "Attach the AGILITY" instructions in the "AGILITY
Installation" section of this manual.
3. Rotate the cane bracket away from the cane.
