C60_3-025_825645_1310_e.p65
75
Example No. 3
76
Example No. 4
76
english
Function Description
Mode 2: Examples for protocol sequence
Write job on Head 1 with parameter Input length 1 = 12 Byte, Output length 1 = 8 Byte
(data carrier type with 32 byte block size):
Host:
1.) Process subaddresses of the output buffer in the
order shown:
01
Enter data
Hex
...
Enter data
Output length 1 Enter data
00
RW-Bit = 1, AV-Bit = 1
Hex
3.) Process subaddresses of the output buffer:
00
AV-Bit = 0
Hex
Function Description
Mode 2: Examples for protocol sequence
Write job on Head 1 with parameter Input length 1 = 12 Byte, Output length 1 = 8 Byte
with write error (data carrier type with 32 byte block size):
Host:
1.) Process subaddresses of the output buffer in the
order shown:
01
Enter data
Hex
...
Enter data
Output length 1 Enter data
00
RW-Bit = 1, AV-Bit = 1
Hex
3.) Process subaddresses of the output buffer:
00
AV-Bit = 0
Hex
BIS C-60_3 Identification System:
2.) Process subaddresses of the input buffer in the
order shown:
00
AA-Bit = 1
Hex
Process subaddresses of the output buffer:
01
Copy data
Hex
...
Copy data
Output length 1 Copy data
Process subaddresses of the input buffer:
00
AE-Bit = 1
Hex
4.) Process subaddresses of the input buffer:
00
AA-Bit = 0, AE-Bit = 0
Hex
english
BIS C-60_3 Identification System:
2.) Process subaddresses of the input buffer in the
order shown:
00
AA-Bit = 1
Hex
Process subaddresses of the output buffer:
01
Copy data
Hex
...
Copy data
Output length 1 Copy data
Process subaddresses of the input buffer:
00
AF-Bit = 1
Hex
4.) Process subaddresses of the input buffer:
00
AA-Bit = 0, AF-Bit = 0
Hex
75
