Example No. 1
74
Example No. 2
74 english
Function Description
Mode 2: Examples for protocol sequence
Read job on Head 1 with Parameter Input length 1 = 12 Byte, Output length 1 = 8 Byte
(data carrier type with 32 byte block size):
Host:
1.) Process subaddresses of the output buffer in the
order shown:
00 RW-Bit = 0, AV-Bit = 1
Hex
3.) Process subaddresses of the input buffer:
01 Copy data
Hex
... Copy data
Input length 1 Copy data
Process subaddresses of the output buffer:
00 AV-Bit = 0
Hex
Function Description
Mode 2: Examples for protocol sequence
Read job on Head 1 with parameter Input length 1 = 12 Byte, Output length 1 = 8 Byte
with read error (data carrier type with 32 byte block size):
Host:
1.) Process subaddresses of the output buffer in the
order shown:
00 RW-Bit = 0, AV-Bit = 1
Hex
3.) Process subaddresses of the output buffer:
00 AV-Bit = 0
Hex
BIS C-60_3 Identification System:
2.) Process subaddresses of the input buffer in the
order shown:
00 AA-Bit = 1, AE-Bit = 1
Hex
01 Enter data
Hex
... Enter data
Input length 1 Enter data
4.) Process subaddresses of the input buffer:
00 AA-Bit = 0, AE-Bit = 0
Hex
english
BIS C-60_3 Identification System:
2.) Process subaddresses of the input buffer in the
order shown:
00 AA-Bit = 1, AF-Bit = 1
Hex
01 invalid
Hex
... invalid
Input length 1 invalid
4.) Process subaddresses of the input buffer:
00 AA-Bit = 0, AF-Bit = 0
Hex
