Manual Start-Up; Interrupting Operation; Putting Out Of Operation; Emergency Start With A Weak Starter Battery - Eisemann BSKA 9,5 EV SS curve Betriebsanleitung

5.6.3.

Manual start-up

Allow the starter cord to run back slowly so that the starter is not damaged!
• There is no need to set the choke since this is operated automatically.
• Pull the starter cord lightly until you feel resistance.
• Then pull the starter cord sharply.
• Repeat both steps until the engine starts.
• Switch the connected consumers on
5.6.4.

Interrupting operation

• Turn the main switch to the "0" position.
The engine will switch itself off.
5.6.5.

Putting out of operation

• Turn the main switch to the "0" position.
The engine will switch itself off.
• Switch the automatic circuit-breakers off.
• Remove all consumers and cables from the socket outlets
5.7.

Emergency start with a weak starter battery

The primer (injection system) allows the B&S Vanguard 22HP engine to be started using the recoil
starter when the battery too weak for an electric start.
Function:
When the primer is actuated, the internal pumping of air draws fuel into the inlet channel of the car-
burettor. This makes it possible to perform a manual start without activation of the fuel valve on the
carburettor.
Operation:
• Turn the main switch (22-12) to the "I" position
• If the engine has been standing for some time and the fuel pipes are empty, close the choke
flap, and ensure a fuel supply by repeated actuation of the recoil starter. (if there is fuel in the
fuel filter, apply suction to the fuel approx. 5x)
• If the engine is cold, close the choke flap (21-3) by hand and operate the primer blowing
bellows (21-2) 3x. After each operation, check that the air can flow freely out of the opening in
the bellows.
Page 32
NOTE
