Introduction
Please read thoroughly this operation manual and
attached safety instructions to enjoy your machine. We
further recommend to retain the operation manual for
future references.
We reserve right to make technical changes for the
purpose of improvement in the course of continuous
product development.
This is the original operation manual.
Scope of supply
Unpack the appliance and check completeness and
delivery of the following components:
•
Wood splitter
•
2 operating arms
• 2 travelling wheels
•
Splitter table
•
Protective arch
•
Lock nut
• Cotter
•
Operating Instructions and warranty certificate
Please contact your seller if you either miss some
components or the components are damaged.
Appliance description
Heavy steel design. Special steel splitter knife. All steel
parts with high-quality powder coating. High-quality
hydraulic pump. Deep slide-in piece including auxiliary
turntable and removable basic table. Engine featuring
overheating protection.
Pic. 1:
1. Handle
2. Splitting knife
3. Clamping plate
4. Operating arm
5. Handle cover
6. Splitter table
7. Wheels
8. Switch / plug
9. Lift adjustment rod
10. Splitting post
11. Filler plug
Technical specifications
Connection:
Engine output:
Engine speed:
Max. hydraulic pressure:
Max. splitting force:
Forward movement speed: 4-5 cm per second
Backward movement
speed:
Splitting post:
Hydraulic oil tank:
Max. split wood diameter:
Max. splitting lift:
Split wood length:
Basis table dimensions:
Weight:
Art. No.
Basic 8T/DTS
400 V~50 Hz
3.6 kW P1/ S6 40%
1,400 revs per minute
210 bar
8 tons
10-12 cm per second
120 x 120 mm
6l (HLP 46 oil)
App. 400 mm
490 mm
590 mm / 860 mm / 1,330
mm
App. 360 mm x 270 mm
App. 125 kg
02030
General safety instructions
Please read carefully the below safety regulations and
Operating Instructions before working with the appliance.
If the appliance is to be given to other persons, provide
such persons with the Operating Instructions, too. Keep
the Operating Instructions in a safe place for future
reference!
•
Check the oil level every time the appliance
is to be used. Add oil if necessary.
•
The appliance may only be operated by one
person!
• Check the appliance visually every time the appliance
is to be used. Do not use the appliance if any safety
equipment is damaged or worn. Never put the safety
equipment out of operation.
•
Do not switch the appliance on if turned over or not in
the operating position.
•
Keep the place of your work clean. Mess in the place
of work may result in injuries.
•
Work under adequate visibility only.
•
Protect the appliance against moisture and rain.
• Do not use electric devices where there is a risk of
fire or explosion.
•
The appliance to be used in broad daylight or under
adequate artificial lighting only.
• Avoid any contact of your body with grounded parts
(e.g. tubes, heaters, cookers, fridges).
•
Never leave the appliance unattended.
• Keep the appliance out of reach of other persons,
especially children and animals and prevent them
from touching the cable.
•
If the appliance is not being used, keep it in a dry
place inaccessible to children.
•
Do not overload the appliance. It works better and
safer within the specified operating range.
• The appliance to be used for purposes mentioned in
these Operating Instructions only.
•
Do not use appliances of poor output for demanding
works.
• Do not wear loose clothing or jewels as they could get
caught by the rotating parts.
•
Wear shoes with a non-slip sole for outdoor works.
• Wear a hairnet if you have long hair.
•
Protective glasses and headphones to be worn at all
times.
•
Make sure your posture is safe - keep balance at all
times.
•
Follow the lubrication instructions.
•
Check regularly the electric device feeder cable and
extension cables and have them replaced by an
expert if damaged.
•
Keep the handles dry, clean and with no oil and fat.
• Unplug the appliance if not being used, before any
servicing or adjusting.
•
Avoid unintentional starting. Make sure the switch is
off when plugging the appliance.
• Approved and properly marked extension cables to
be used outdoors only.
•
Pay attention to what you are doing. Use common
sense when working. Do not use the electric device
when you are not concentrated.
•
Before using the electric tools the next time, it is
necessary to carefully check whether the protective
equipment or slightly damaged parts work perfectly
and as required and replace them if necessary.
•
All parts on the appliance must be regularly checked
for any signs of damage or aging. The appliance must
not be used if not in a perfect state.
•
Do not use electric devices where the switch cannot
be put on or off.
• Original spare parts for repairs to be used only.
