P 6 Ratio Width to Thin (default: 0 (2 to 1))
Code 93, MSI 10/10, Code 128 are fixed 2.0 to 1
Note:
Best results for Code 39, 2 of 5 industrial, 2 of 5 interleaved, and Codabar
with 2.5 to 1
P 7 Uni-directional or bi-directional printing - standard 0 uni-directional
values are:
0 or not programmed means no changes
1 uni-directional printing in LQ
2 bi-directional printing in LQ
3 uni-directional printing in NLQ
4 bi-directional printing in NLQ
Start Position of Barcode Printing
The start position for barcode printing is the current print position. For both
horizontal and vertical printing, the print position after printing barcodes is the
same line as the start position next to the barcode printed.
F-4
Code 39
2 of 5 industrial
P 6
2 of 5
interleaved
value
Codabar
Code 93
MSI mod 10/10
Code 128
0
1
2
3
EAN 8
EAN 13
UPC-A
UPC-E
2.0 to 1
2.5 to 1
3.0 to 1
3.5 to 1
Appendix F Barcode Quick Reference
SC3
SC6
SC9
SC3
