Table 6: Graphic Modes
Escape Sequence
ESC * P1 P2 P3 v1 . . . vn
Parameter Table Graphic Density:
P1 Graphic type
0/0 Standard Density (K)
0/1 Double Density (L)
0/2 2xDensity / 2xSpeed (Y)
0/3 Quadruple Density (Z)
0/4 CRT I
0/6 CRT II
2/0 Standard Density
2/1 Double Density
2/6 CRT III
2/7 Triple Density
2/8 Hex Density
*) consecutive horizontal dots cannot be printed.
Example: box 8x8 dots with center point 2x2 dots, standard density, 8 dots / column
hex: 1B 2A 00 08 00 FF 81 81 99 99 81 81 FF
E-14
Function
Select Various Graphics Modes
P2 + P3 * 256 = number of columns v1 .. vn
(0/0...F/F)
binary data in hex code
(0/0...F/F)
dots / max. number
column of columns
8 816
8 1632
8 1632
8 3264
8 1088
8 1224
24 816
24 1632
24 1224
24 2448
24 4896
Appendix E EPSON LQ ESC/P2, Quick Reference
hor. density
( dpi )
60
120
120
240
80
90
60
120
90
180
360
*)
*)
*)
