PSI Matrix PP 803 Benutzerhandbuch Seite 271

Appendix D IBM ProPrinter Quick Refernce
Table 7: Further Control Sequences, supported by IBM Emulation Mode
(Native Commands)
Escape Sequence
ESC [
ESC
ESC * P1 P2 P3 v1 . . . vn
Parameter Table Graphic Density:
P1 Graphic type
0/0 Standard Density (K)
0/1 Double Density (L)
0/2 2xDensity / 2xSpeed (Y)
0/3 Quadruple Density (Z)
0/4 CRT I
0/5 Plotter
0/6 CRT II
0/B Double Density Plotter
2/0 Standard Density
2/1 Double Density
2/6 CRT III
2/7 Triple Density
2/8 Hex Density
*) consecutive horizontal dots cannot be printed.
Example: box 8x8 dots with center point 2x2 dots, standard density, 8 dots /
column hex: 1B 2A 00 08 00 FF 81 81 99 99 81 81 FF
Function
$$ Control String Introducer (CSI) for 'ESC ['
$$/ Control String Introducer (CSI) for 'ESC'
Select Various Graphics Modes
P2 + P3 * 256 = number of columns
(P2,P3 = 0/0...F/F) v1 .. vn = binary data in hex code
dots max. of
per
column columns
8 1632
8 816
8 1632
8 3264
8 1088
8 979
8 1224
8 1958
24 816
24 1632
24 1224
24 2448
24 4896
hor. vert.
density density
( dpi ) no AGM
120 72
60 72
120 72
240 72
80 72
72 72
90 72
144 72
60 180
120 180
90 180
180 180
360 180
vert.
density
AGM
60
60
60 *)
60 *)
60
60
*)
180
180
180
180
180 *)
D-13
