PSI Matrix PP 803 Benutzerhandbuch Seite 313

Appendix F Barcode Quick Reference
P4 Width of the thin bars (default:
Note: The width of bars and gaps should be equal. For this, the parameters P4
and P5 should not deviate more than one step.
for horizontal Barcode
P4
0
1
2
3
4
5
6
7
for vertical Barcode
P4
0
1
2
3
4
5
6
7
P5 Width of the thin gaps (default:
The values are the same as in P4
hex dec
30 48
31 49
32 50
33 51
34 52
35 53
36 54
37 55
hex dec
30 48
31 49
32 50
33 51
34 52
35 53
36 54
37 55
/ " = 0.35 mm)
2
144
inch mm
2/144 0,35
3/144 0,53
4/144 0,70
5/144 0,88
6/144 1,05
7/144 1,23
8/144 1,41
9/144 1,58
inch mm
2/180 0,28
3/180 0,42
4/180 0,56
5/180 0,70
6/180 0,85
7/180 0,99
8/180 1,12
9/180 1,27
2
/ " = 0.35 mm)
180
F-3
