PSI Matrix PP 803 Benutzerhandbuch Seite 300

Table 9: EPSON Barcodes Commands
Escape Sequence
ESC ( B P1 P2 k m s v1 v2 c
BarCodeData
P1 P2 number of data bytes to follow: 6 bytes + number of BarCodeData = P1 + P2 x 256
k specifies the barcode type: k = 0/2 Interleaved 2 of 5
k = 0/5 Code 39 k = 06 Code 128
m specifies the module width (unit 1/180 inch)
m = 0/2 2 dots (default)
m = 0/3 3 dots m = 0/4 4 dots m = 0/5 5 dots
s specifies the space adjustment value (unit 1/360 inch) -3 <= s <= 3 (F/D <= s <= 0/3)
v1 and v2 specifies the bar length (v1+v2x256) (unit 1/180 inch) range : 45/180 inch <= bar
legth <= 8.25 inch c specifies the control flag
bit 0 : Check digit 0: host generates check digit 1: printer generates check digit
bit 1 : human readable character 0: print hr character ; 1: no print of character bit 2 to
bit 7 : reserved
Actual number of barcode data Interleaved 2 of 5 : 2 .. 255
Code 39 :
Code 128 :
Valid range of BarCodeData Interleaved 2 of 5 : 0 9 (30H 39H)
Code 39
(41H - 5AH) (20H, 24H, 25H, 2BH, 2DH, 2EH, 2FH)
Code 128 : uses the code sets A, B, and C
Code sets A, B, and C:
Data characters
Code A
Code B
Code C
Shift
FNC 1
FNC 2
FNC 3
FNC 4
E-20
Function
1 .. 255
2 .. 255
: 0 9 (30H 39H),
Code set A
x00 x5F
x64
x63
x62
x66
x61
x60
x65
Specify and Print barcode
Code set B
x20 - x7F
- x1E
-
x1C
x1B
x1F
x1A
x19
x1D
Appendix E EPSON LQ ESC/P2, Quick Reference
Code Set C
x30 x39
x3B
x3A
-
-
x3C
-
-
-
