PSI Matrix PP 803 Benutzerhandbuch Seite 304

Table 10: Further Control Sequences, supported by EPSON LQ
Emulation Mode (Native Commands)
(Native Commands)
Escape Sequence Mnemonic
ESC [ ; P2 ; P3 ; P4 ; P5 ; P6 ; P7 SP z
see Appendix F
BARCODE Programming
ESC [ ? 0 h
ESC [ ? 0 l
E-24
Function
BH Barcode Header
P2:
P3:
P4:
P5:
P6:
P7:
0 :
1 :
2 :
3 :
4 :
SMBC Set Mode Barcode
RSBC Reset Mode Barcode
Appendix E EPSON LQ ESC/P2, Quick Reference
Barcode typ
Height of barcode
Width of the thin bars
Width of the thin gaps
Ratio width to thin (bars / gaps)
Uni-directional or bi-directional printing
or not programmed: means no changes
uni-directional printing in LQ
bi-directional printing in LQ
uni-directional printing in NLQ
bi-directional printing in NLQ
