PSI Matrix PP 803 Benutzerhandbuch Seite 283

Appendix E EPSON LQ, ESC/P2, Quick Reference
Vertical Form Handling
The printer is always equipped with two continuous form tractors. The last sheet
of a continuous form stack can be printed on up to the end of the form.
The capabillity of the printer to feed paper from different sources is optimally
supplemented by the option that automatically adjust the distance between the
print head and the print bar.
Table 4: Vertical Form Handling
Escape Sequence
ESC 0
ESC 2
ESC 3 P1
ESC + P1
ESC A P1
ESC B NUL
ESC B P1 P2 P16 NUL Set Vertical Tabs
. .
ESC C P1
ESC C NUL P1
ESC J P1
ESC N P1
ESC O
ESC b P1 P2 P16 NUL Set Vertical Tabs in Channel P1
..
Function
Set Line Space to 1/8"
Set Line Space to 1/6"
Set Line Space to P1/180"
Set Line Space to P1/360"
Set Line Space to P1/60"
Clear Vertical Tabs
Set Form Length in Lines
Set Form Length in Inches
Perform P1/180" Line Feed
Set Automatic Perforation Skip
P1 is the number of lines from bottom of paper to skip.
(P1 = 0/1...7/F)
Cancel Automatic Perforation Skip
P1 = 0/0 .. 0/7 : channel 0 - 7
P2..P16 = line number
(P1 =0/ 0...F/F)
(P1 = 0/0...F/F)
(P1 = 0/0...7/F)
(P1...P16 = 0/1...F/F)
(P1 = 0/1...7/F)
(P1 = 0/1...1/6)
(P1 = 0/0...F/F)
(P2..P16 = 0/1..F/F)
E-3
