EDK82ZAFB
00416074
10/01
These Instructions
Ÿ contain the most important technical data, installation, handling and commissioning instructions
for the function module.
Ÿ are only valid
- for function modules with the nameplate data E82ZAFB001
- together with the Mounting Instructions for the 8200 motec
- together with the Mounting Instructions for the field bus function module motec
Description
The E82ZAFB001 function module is used to connect 8200 motec inverters
Ÿ with a serial communication network and
Ÿ control the 8200 motec through digital and analog control signals.
Range of application
Operation of the Bus I/O is only possible together with the following units:
Ÿ 8200 motec frequency inverters 0.55 ... 2.2 kW as of nameplate code
- E82MVxxx_4BxxxXXxx1x
Ÿ Bus function modules with the following nameplates:
INTERBUS
PROFIBUS-DP
LECOM-B (RS485) E82ZAFL 001 (VB01)
System bus CAN
Items supplied
0
Bus I/O (I/O function module with flexible PCB
and mounting frame for bus function modules)
1
1 screen sheet for Bus I/O
2
3 screws M3 x 10 for screen sheet and frame
mounting
Accessories required
1 bus function module (e. g. INTERBUS E82ZAFI001)
l
Function module E82ZMFB001
Bus-I/O for 8200 motec 0.55/2.2 kW
E82ZAFI 001 (VB01)
E82ZAFP 001 (VC02)
E82ZAFC 001 (1C00)
L
Type
Id.-No.
Prod.-No.
Ser.-No.
E82AF000 0B001XX
Lenze GmbH & Co KG, Postfach 10 13 52, D-31763 Hameln
( (+49) 5154 82-0, Fax Service: (+49) 5154 82-1112
¨
0
1
2
EDK82ZAFB 2.0
