1. If necessary, dismount the
screen sheet (delivered
together with the motec)
2. Mount the screen sheet 0
(included in the delivery
package for the Bus I/O)
3. Mount the motec carrier
housing to the motor or the
wall (see Mounting
Instructions for motec)
4. Insert Bus I/O into motec
carrier housing
5. Mount the mounting
screws with 2 screws
M3 x 10
l
Installation
O
0,7 Nm
6 lbin
M3x10
- 3 -
8200BUS004
motec
550 / 750 W
motec
1.5 / 2.2 kW
8200BUS002
EDK82ZAFB 2.0
