PRODUCT PARTS
EN
(1) Backrest
(2) Adjustable Headrest
(3) Booster
(4) Headrest Height Adjuster
(5) Shoulder Belt Guide
(6) Linear Side­impact Protection
(L.S.P.)
(7) Lap Belt Guide
(8) ISOFIX Locking Arms
THE CORRECT POSITION IN THE VEHICLE
With retracted ISOFIX­locking arms (8) the car seat can be used on vehicle
seats which are equipped with an automatic three point belt. For using ISOFIX
please refer to the enclosed vehicle type list for approved vehicles. You can
obtain the most up­to­date version from www.cybex-online.com.
Above a child's stature of 135cm, the compatibility between the Solution G
i­Fix and your vehicle might be reduced. Please review the vehicle type list
to check whether the child seat can be used in all headrest positions without
restrictions. In exceptional cases, the child car seat may also be used on the
front passenger seat. Always comply with the recommendations of the vehicle
manufacturer.
INSTALLING THE CAR SEAT IN THE VEHICLE
1. Always ensure that...
• the backrests in the vehicle are locked in their upright position.
• when installing the car seat on the front passenger seat, adjust the vehicle
seat as far back as possible without affecting the belt routing.
2. Before installation, make sure that the car seat is in the seating position.
3. Release the ISOFIX Release Buttons (10) to extend the ISOFIX Locking Arms
(8).
The ISOFIX Release Buttons can both be released independently allowing
��
the ISOFIX Locking Arms to be adjusted independently.
4. Push the ISOFIX Locking Arms (8) out of the base to their furthest extent.
5. Place the car seat on an appropriate seat in the car.
6
(9) ISOFIX Anchorage Points
(10) ISOFIX Release Buttons
(11) ISOFIX Safety Indicator
(12) User Guide Storage Compartment
(13) Side Impact Protection Release
Button
(14) Position Adjustment Button
(15) Reclining Headrest
6. Push the ISOFIX Locking Arms (8) into the ISOFIX Anchorage Points (9)
until these lock into place with an audible "CLICK". The two ISOFIX Safety
Indicators (11) will switch from red to green.
7. Ensure the seat is secure by trying to pull it out of the ISOFIX Anchorage
Points (9).
8. Push the car seat towards the backrest of the vehicle seat until it is fully
aligned with the backrest.
If the headrest of the vehicle is in the way, pull it upwards to its furthest
��
extent or remove it completely (except in rear­facing vehicle seats).
9. The seat can be brought into a sitting or recline position by pressing the
position adjustment button (14) and moving the seat forward or push back.
REMOVING THE CAR SEAT FROM THE VEHICLE
Perform the installation steps in the reverse order.
1. Unlock the ISOFIX Locking Arms (8) on both sides by pushing the ISOFIX
Release Buttons (10) and pulling them back simultaneously.
2. Pull the seat away from the ISOFIX Anchorage Points (9).
3. Remove the car seat and push the ISOFIX Locking Arms (8) fully back into
the transport position.
ADJUSTING THE HEADREST
The Adjustable Headrest (2) can be adjusted by using the Headrest Height
Adjuster (4) at the back of the headrest (2). Adjust the headrest so that max.
2 cm (approx. 2 finger's width) remain between the child's shoulder and the
headrest.
The height of the headrest can still be adjusted while the seat is installed in
��
car.CORRECT INSTALLATION MODE
the
CORRECT INSTALLATION MODE
100 cm – 150 cm
