Output

Output signal
Current
Step response T
90
Burden
4 to 20 mA, 2-wire
Burden influence
4.4

Mechanical features

Material
Process connection
Protective cap
Membrane
Housing
Electrical connection
Cable
Conductor cross section
Bending radius
Weight
Explosion protection
4 to 20 mA, 2-wire
≤ 3 ms
R ≤ (U -16 V) ÷ 0.022 A (Ω)
B B
≤ 0:004 % pro 100 Ω
316Ti
PVC (for M12 × 1 with protective cap)
316L
304
304, PA (for round plug M12 × 1)
304, PUR (for attached cable)
PUR
2
0.22 mm
Max. 35 mm
Approx. 55 g
ATEX: II 2G Ex ib IIC T6 ... T4 Gb
ATEX: II 2D Ex ib IIIC T70°C ... T100°C Db
IEC Ex: Ex ib IIC T6 ... T4 Gb
IEC Ex: Ex ib IIIC T70°C ... T100°C Db
