Align the scale to the markings. To do so, slide the rip fence
(16) onto the blue/black zero marking in accordance with
the display on the sight glass (p) on the rip fence (16).
13. Once the scale is aligned, tightly fasten the four nuts of the
carriage bolts to fix the guide rail in place.
Check the position of the riving knife before ini-
tial start-up. The riving knife is set to the lowest
position for transporting.

Replacing the Table Insert

(Figures 18)
1. If it is worn or damaged, the table insert (5) has to be re-
placed, as otherwise there is an increased risk of injury.
2. Remove the 2 countersunk screws (26).
3. Slightly raise the table insert (5) at the back and slide back-
wards in the direction of the arrow. Take out the table insert
(5). The left-hand side of the central part of the table insert (5)
may require slight adjustment to release the nose of the table
insert (5).
4. The new table insert is mounted in reverse order.

Attaching/changing the saw blade

(Figure 3+18-21)
1. Attention! Remove the mains plug and wear pro-
tective gloves.
2. Remove the saw blade guard (2).
3. Remove the laser (28) by loosening the screws (z).
4. Remove the table insert (5) (see "Replacing the Table Insert")
5. Loosen the clamping screw (11). Tilt the saw blade (4) by
turning the handwheel (9) in order to attach the Allen key (h)
and ring spanner (k) more easily.
6. Place the Allen key (h) (HX 6) on the bolt and use the ring
spanner (k) (AF 22) to stop the motor schaft from turning.
7. Attention! Turn the bolt in the direction of rotation of the
saw blade. Remove the loosened screw.
8. Remove the outer flange and take the old saw blade off the
inner flange by pulling downwards and diagonally.
9. Clean the saw blade flanges carefully with a wire brush be-
fore attaching the new saw blade.
10. Insert and tighten the new saw blade in reverse order.
Attention! Note the direction of motion; the slope
of the cutting edge of the teeth must face the direc-
tion of motion, i.e. forwards.
11. Reattach and adjust the table insert (5) and the saw blade
guard (2).
12. Reattach the laser (28). Observe the chapter "Adjusting the
Laser".
13. Before you work with the saw again, a check must be carried
out to ensure that the protective devices are working properly.
Follow the instructions below when assembling
saw blades:
- Saw blades must be tightened in such a way that they can-
not become loose during operation.
- Make sure that assembly is performed only on the tool
hubs or the tightening surface of the saw blades, and that
the cutting edges do not come into contact with the tighten-
ing elements.
- Tighten the mounting screw using only a suitable spanner
and a torque of 2.25 - 2.75 Nm.
- Extending the spanner or tightening with the help of ham-
mer blows is not permitted.
- Clean the tightening surfaces to remove any dirt, grease,
oil and water.
- Tighten the tensioning bolts only in accordance with the
manufacturer's instructions.
Mount/adjust the riving knife;
insert the battery
Attention! Remove the mains plug! The setting
of the saw blade (4) must be checked whenever
a blade has been replaced.
(Figures 18-22)
1. Adjust the saw blade (4) to a max. cutting depth, move to the
0° position and lock in place.
2. Remove the saw blade guard (2) (not during initial assembly).
3. Remove the laser (28) by loosening the screws (z).
4. Loosen the two countersunk screws of the table insert (26)
and take out the table insert (5).
5. Loosen the mounting screw (27) (use the open-ended spanner
AF8 supplied).
6. Slide the riving knife (3) all the way up.
7. Retighten the mounting screw (27).
8. Reattach the table insert (5).
9. Reattach the laser (28). Observe the chapter "Adjusting the
Laser".
10. Reattach the saw blade guard (2).
11. Inserting the batteries:
- Turn the laser on/off switch (29) to the
"0" position (laser off).
- Remove the battery compartment cover (31) by loosening
the screw (30). Now remove the battery compartment cov-
er (31) by bending at the side.
- Insert the batteries supplied (type AAA), ensuring the cor-
rect polarity
- Put the battery compartment cover (31) back in position
and tighten it with the screw (30).
Notes concerning the batteries:
- If you are not going to use the laser for a prolonged peri-
od, please remove the batteries from the battery compart-
ment. Otherwise, the leaking of battery fluid might dam-
age the device.
- Do not place the batteries on radiators or expose them for
a prolonged period to strong sunlight; temperatures above
45° could damage the device.
Mounting / dismounting the saw blade
guard
(Figures 23)
On first assembly, the assembly of the saw
blade protection has already been carried out
in the previous assembly step.
1. Loosen the knurled nut (32) and wing nut of the saw blade
guard (2). Place the saw blade guard (2) from the top onto
the riving knife (3).
2. Mount the screw with knurled nut (32) and wing nut as de-
picted.
3. Tighten the screw (32). The saw blade guard must be able to
move freely.
4. Dismantling is carried out in reverse order. Caution! Before
you start sawing, the saw blade guard (2) has to be lowered
onto the item being sawn.
